Database Backup System

Production Disaster Recovery

Overview

An automated disaster recovery solution for a production trading platform. Running daily, it creates compressed backups of the entire database, uploads to AWS S3, and maintains a retention policy with email notifications on success or failure.

The Problem

The trading platform manages critical business data:

• 3.7 million rows of transaction history
• 52 tables of operational data
• Regulatory requirements for data retention
• Business continuity needs for rapid recovery

Without proper backups, a database failure could mean:

• Loss of transaction records
• Regulatory compliance violations
• Significant business disruption

Solution Architecture

SQL Server Database
       |
   [Daily 5:45 PM]
       |
  Node.js Backup Service
       |
   ┌───┴───┐
   |       |
 Compress  Validate
   |       |
   └───┬───┘
       |
   AWS S3 Upload
       |
   Email Notification

Backup Process

1. Connection: Secure connection to SQL Server via credentials from AWS Secrets Manager
2. Export: Table-by-table data extraction with transaction consistency
3. Compression: GZIP compression reducing ~40MB raw to ~8.7MB
4. Upload: Encrypted upload to S3 with versioning enabled
5. Notification: Success/failure email via AWS SES

Technical Implementation

Data Volume

Production Statistics:
- Tables: 52
- Total Rows: 3,744,892
- Largest Table: 2.1M rows (transaction_lines)
- Backup Size: ~8.7 MB compressed
- Backup Duration: ~45 seconds

AWS Integration

S3 Storage

• Versioned bucket for point-in-time recovery
• Lifecycle rules for cost optimization
• Cross-region replication for DR

Secrets Manager

• Database credentials rotated quarterly
• IAM role-based access
• No secrets in code or config files

SES Notifications

• Success emails with backup statistics
• Failure alerts with error details
• Branded HTML templates

Scheduling

# systemd timer for daily backups
[Timer]
OnCalendar=*-*-* 17:45:00
Persistent=true

[Install]
WantedBy=timers.target

Recovery Capabilities

Recovery Time Objective (RTO)

• Target: Under 10 minutes
• Tested: 7 minutes average
• Process: Download, decompress, restore

Recovery Point Objective (RPO)

• Maximum data loss: 24 hours
• Backup frequency: Daily
• Retention: 90 days

Recovery Procedure

1. Download latest backup from S3
2. Verify checksum integrity
3. Decompress backup file
4. Restore to SQL Server instance
5. Validate row counts against manifest

Monitoring & Alerting

Success Metrics Tracked

• Backup duration
• Compressed file size
• Row counts per table
• S3 upload confirmation

Failure Handling

• Immediate email alert on any error
• Error details and stack trace included
• Manual intervention instructions

Results

Since deployment:

• 100% backup success rate
• Zero data loss incidents
• Full compliance with regulatory requirements
• Proven recovery during planned DR tests

This project demonstrates database administration skills, AWS service integration, and building reliable disaster recovery systems for production environments.
